PCV60 and PCV100 in More Detail
A closer look at the PCV60 and PCV100 constant voltage LED drivers, highlighting their key design improvements, performance characteristics, and suitability for LED lighting applications. The guide focuses on features such as reduced inrush current in newer revisions, helping improve system reliability while maintaining efficient and stable power delivery.
Latch Off Protection Circuitry
EN/IEC 61347-1 & 2-13 Approved
EN and IEC identify whether a product has been tested for use within the EU or worldwide. IEC is the International Electrotechnical Commission; EN is for European Standards. 61347-1 refers to the general and safety requirements of Lamp control gear. 61347-2-13 is specific to the DC or AC supplied by control gear to LED modules at SELV or higher voltages. Full reports are available for both our PCV60 & PCV100 Ranges.
LED Indication for Power OK
The LED indicator is on the output side, rather than the input like other products on the market, to make DC OK easily identifiable; specially in Latch Off conditions. So you know functioning power is present at a glance!
IP20 Compliant Terminations
The enclosure offers IP20 compliant terminations, with no cabling installed. It provides protection against access by medium sized foreign bodies >12.5mm. There is no protection provided by the enclosure against harmful ingress of water; therefore, the unit is only recommended for indoor use unless mounted within a suitable enclosure.
Low Inrush
PCV60 and PCV100, REV-C incorporate low inrush current circuitry, which offers reduced inrush current figures in comparison to other Switch Mode Power Supplies. This is particularly useful in applications with older or sensitive AC circuits, MCBs and Breakers and will allow for a much greater install quantity per circuit without nuisance tripping.
*All Revision C models offer <20A inrush current Peak (@ 230VAC, cold start and full load).
Power Factor Range
PCV60 and PCV100, REV-C have an extended power factor range. This means that the product will operate with a high power factor figure even when not at full load, allowing for a much larger scope of application. Combined with the product's high efficiency levels, optimum overall power usage is available for the majority of installations.
| Model | Voltage | Current | Power | Inrush Current | Efficacy | PFC |
| PCV1260-REV-C | 12VDC | 5A | 60W | <20A | 84% | 0.96 |
| PCV2460-REV-C | 24VDC | 2.5A | 60W | <20A | 84% | 0.96 |
| PCV12100-REV-C | 12VDC | 8.33A | 100W | <20A | 84% | 0.96 |
| PCV24100-REV-C | 24VDC | 4.16A | 100W | <20A | 84% | 0.96 |
