• Universal AC input 90 to 264VAC
  • Low ripple and noise
  • Over voltage and short circuit protection
  • Safety: UL/CUL, CE, TUV, DoIR, C-Tick
  • AC Plugs: USA, TUV, UK, SAA PIN
  • Interchangeable AC plugs (plug kit available separately)
A compact Wall Mount Switchmode AC-DC Adapter designed for worldwide applications. Featuring over voltage, short circuit and open circuit protections and UL/cUL, CE & TUV safety approvals. The interchangeable AC plugs make the EA1015-BR Series ideal for portable applications that target the consumer market such as MP3 players, mobile phones etc. and for corporate applications that target the worldwide market, such as POS.

Additional information

Current (amps) 1A, 2A
Efficiency (%) 78%, 29%, 73%, 79%
Power (watts) 10W, 12W, 15W
R&N (mV) 100mV, 180mV, 240mV, 250mV, 285mV, 350mV
Voltage (max/rated) 12V, 15V, 18V, 24V, 5V, 9V
  • MP3 Players
  • i-pods
  • POS
