Features
  • Switching Power Modules for PCB Mounting
  • Fully Encapsulated Plastic Case
  • Universal Input Range 90-264VAC, 47-440Hz
  • Regulated Output
  • Low Ripple and Noise
  • High Efficiency
  • CE, cUL, TUV Approvals

1.5A slow blow type external fuse recommended. Free air convection cooling

Additional information

Manufacturer
Standards
Type
Outputs
Current (amps) 0A, 1A
Efficiency (%) 73%, 74%, 75%
Power (watts) 10W, 8W
R&N (mV) 50mV
Voltage (max/rated) 12V, 15V, 5V

Products in this Range

Part number Power (watts) Voltage (max/rated) Current (amps) R&N (mV) Efficiency (%)
ATC-12D 10W 12V 0A 50mV 75% Request Quote
ATC-15D 10W 15V 0A 50mV 74% Request Quote
ATC-5D 8W 5V 1A 50mV 73% Request Quote
