MPM-05 is a 5W high density and small sized AC/DC module type medical grade power supply series offered in pin type.
Features
- 1.8″x1″ compact size
- Medical safety approved (2 x MOPP) according to ANSI/AAMI WS60601-1 and IEC/EN60601-1
- Suitable for BF application with appropriate system consideration
- NO load power consumption <0.075W
- Extremely low leakage current
- Wide operating temp range -40~+85C
- EMI Class B for Class II configuration
- Protections: Short circuit/ Overload/ Over voltage/ Over temperature
- No minimum load required
- Typical lifetime > 48K hours
- 3 years warranty
MPM-05 is a 5W high density and miniature (45.7×25.4×21.5mm) AC/DC module type medical grade power supply series offered in pin type. It features 80~264VAC, a no load power consumption less than 0.075W, a high efficiency up to 82%, Class II (no FG) double insulation, outstanding dissipation and high lifespan thanks to the interior potting, 5G anti-Vibration, high EMC performance, 4KVAC isolation. The design observes IEC/EN60601-1 and ANSI/AAMI ES60601-1 version three 2XMOPP level and ultra low leakage current (<80 A) It is very suitable for BF (patient contact) type medical device or relevant equipment. These two series are able to be applied to type BF (Body Floating, patient contact type) medical equipment. Suitable applications include medical testing apparatus, portable medical devices, and medical equipment requiring extremely low standby power consumption.
Additional information
Weight | 0.04 kg |
---|---|
Inputs | 80 ~ 264VAC |
Manufacturer | MEAN WELL |
Type | AC/DC, Encapsulated, Medical Grade, Open Frame, PCB Mount |
- Portable medical device
- Mobile clinical workstation
- Medical computer monitor
- Medical examination instrument
- PM-05 Series
Products in this Range
Part number | Power (watts) | Current (amps) | Inputs | |
---|---|---|---|---|
MPM-05-12 | 5W | 80 ~ 264VAC | Request Quote | |
MPM-05-15 | 5W | 80 ~ 264VAC | Request Quote | |
MPM-05-24 | 5.5W | 80 ~ 264VAC | Request Quote | |
MPM-05-3.3 | 4.1W | 80 ~ 264VAC | Request Quote | |
MPM-05-5 | 5W | 1A | 80 ~ 264VAC | Request Quote |
