DRC-180B
179.4W 27.6VDC 27.6VDC 4.5A 2A UPS Function DIN Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- Alarm signal for AC OK and Battery Low (Via Relay)
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Battery low protection / Battery reverse polarity protection by fuse
- Built-in active PFC function
- Can be installed on DIN rail TS-35/7.5 or 15
- 20 ~ +70°C wide operating temperature
- 3 years warranty
- Cooling by free air convection
- Operating altitude up to 5000 meters (Note.6)
- Universal AC input / Full range
- DC output voltage adjustable (±20%)
- LED indication for Power on
Description
DRC-180 is a 180W AC/DC DIN rail type security power supply series. In addition to the primary output, there is a charger output with a smaller rated current, enabling the backup power supply application the security access systems require. DRC-180 accepts the universal input between 90VAC and 264VAC, and supplies 13.8VDC and 27.6VDC at output, respectively. With the efficiency up to 90%, it can operate with air convection cooling under -20°C through 70°C. In addition to the key protection features such as overload protection, over voltage protection, battery low cut off, and battery reverse polarity protection (by fuse), the alarm signal for AC OK and battery low signaling is provided, via relay contact output, to facilitate the system design.
