DRC-100B
96.6W 27.6V 2.25A 27.6V 1.25A UPS Function DIN Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- Cooling by free air convection
- Protections: Short circuit / Overload / Over voltage
- Universal AC input / Full range
- LED indicator for power on
- 100% full load burn-in test
- Can be installed on DIN rail TS-35/7.5 or 15
- Alarm signal for AC OK and Battery low (via relay)
- Battery low protection / Battery reverse polarity protection by fuse
- 3 years warranty
Description
DRC-100 is a 96W AC/DC DIN rail type security power supply series. In addition to the primary output, there is a charger output with a smaller rated current, enabling the backup power supply application the security access systems require. DRC-100 accepts the universal input between 90VAC and 264VAC, and supplies 13.8VDC and 27.6VDC at output, respectively. With the efficiency up to 89%, it can operate with air convection cooling under -30°C through 70°C. In addition to the key protection features such as overload protection, over voltage protection, battery low cut off, and battery reverse polarity protection (by fuse), the alarm signal for AC OK and battery low signaling is provided, via relay contact output, to facilitate the system design.
