CB1235A
12V 35A DIN Rail 3 Level Battery Charger Please ring us to discuss a great price for this product.Product Features
- Five-stage IUoU charging: Recovery, Bulk, Absorption, Boost, Float
- Input range: 90–135VAC / 180–305VAC single-phase
- Supports Lead Acid, Gel, Ni-Cd (optional), and Li-Ion batteries
- DIN rail mounting with compact IP20-rated housing
- Signal outputs: main/backup, low battery, battery fault (free contacts)
- Automatic charging curve with quiescent current ≤ 5mA
- 12VDC output with 35A max battery charging current
- LED blink diagnostics for system and battery faults
- Modbus RTU enabled via RS485 for remote monitoring
- Short-circuit, overload, and reverse polarity protection
Description
The CB1235A is a 12VDC 35A DIN rail battery charger that combines advanced multi-stage charging, diagnostic capabilities, and industrial-grade protection. Designed using Adel System's proprietary Battery Care philosophy, it supports multiple battery chemistries including Open Lead Acid, Sealed Lead Acid, Gel, Ni-Cd (optional), and Lithium-Ion.The charging algorithm features five programmable stages: Recovery, Bulk, Absorption, Boost, and Float, ensuring optimal battery performance and extended life. Intelligent diagnostics monitor conditions like reverse polarity, disconnected battery, or internal short circuits and signal faults using front-panel LEDs with blink codes.Modbus RTU support via RS485 allows integration into supervisory systems for real-time monitoring. Signal outputs (free contact relays) provide system status for main/backup power, low battery, and battery fault. The unit includes robust protections against short circuits, overload, reverse polarity, and output overvoltage, ensuring dependable performance across demanding applications.
