CBI1210A
12V 10A Modbus RTU Enabled All-in-One DC-UPS Please ring us to discuss a great price for this product.Product Features
- Compatible with lead-acid, gel, Li-Ion and Ni-Cd batteries
- DIN rail mount, IP20 enclosure, compact L135 x W65 x H115mm
- Load-first priority with automatic current distribution
- All-in-One DC-UPS with integrated power supply, charger and backup
- Start-up from battery without AC input
- Diagnostic LEDs and dry contact relays for fault and battery status
- IUoU 4-stage charging with selectable boost/float profiles
- Wide AC input: 90–305VAC
Description
The CBI1210A is a 120W all-in-one DC-UPS engineered for systems requiring dependable 12VDC uninterrupted power. It integrates a power supply, battery charger, backup switch, and advanced diagnostics into one DIN-rail unit.With a 10A rated output and 10A charging capability, it ensures the load is powered directly and the battery is charged smartly via an IUoU curve, complete with Battery Care features like diagnostics, sulfation detection, and polarity protection.The unit offers a high inrush capability (up to three times the rated current), supports a variety of battery chemistries, and features automatic load-first logic. Faults and battery issues are easily flagged using blink codes, relay contacts, or an optional Modbus RTU. The 120W module accepts 90–305 VAC input and supports starting from battery if mains fail.
