CBI4810A
48V 12.5A Modbus RTU Enabled All-in-One DC-UPS Please ring us to discuss a great price for this product.Product Features
- Programmable relay outputs for system and battery alarms
- Modbus RTU communication over RS485 for full system data
- Advanced Battery Care with diagnostics, recovery, and sulfation detection
- Automatic prioritisation of load power over battery charging
- IP20 rated, compact DIN-rail housing
- Remote start from battery via RTCONN cable
- IUoU smart charging curve with 5 stages: Recovery, Bulk, Absorption, Boost, and Float
- Compatible with Lead Acid (open/sealed/gel), Ni-Cd, Ni-MH, and Li-Ion batteries
- Integrated DC-UPS with power supply, battery charger, and monitoring system
Description
The CBI4810A is a 600W All-in-One DC-UPS delivering 48VDC at up to 12.5A, combining a power supply, battery charger, backup module, and monitoring system in a single DIN-rail mountable unit. Designed for critical systems that demand uninterrupted DC power, it uses ADELSystem’s IUoU 5-stage charging algorithm with Battery Care diagnostics to ensure extended battery life and reliability.Modbus RTU support via RS485 enables full system visibility and integration with industrial monitoring platforms. Load prioritisation ensures system stability by allocating available power to the load before charging the battery. It includes protections for short circuits, reverse polarity, deep discharge, and provides programmable relay outputs for fault signalling.Suitable for various battery chemistries including Lead Acid, Ni-Cd, Ni-MH, and Lithium-Ion, this compact IP20 device is ideal for harsh electrical environments that require high efficiency and reliability.
