DRF-12V120W1PBA
120W 10A 12VDC High Reliability DIN Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- 85–277VAC or 100–400VDC wide input range
- Withstands 305VAC input for 60 seconds
- Power Boost: 150% for 5 seconds, 200% for 50ms and 500% for 5ms
- Full-load operation up to +60°C
- Wide -40°C to +80°C operating temperature range with derating
- DC OK relay contact and LED status indication
- Remote ON/OFF control
- Conformal coating for additional PCB protection
- Short-circuit, overload and over-voltage protection
- SEMI F47 compliance, Class B EMC performance and 5-year warranty
Description
The Delta DRF-12V120W1PBA is a compact industrial DIN rail power supply delivering 12VDC at 10A with 120W rated output. It accepts 85–277VAC or 100–400VDC input and can withstand 305VAC for 60 seconds, supporting reliable integration across demanding industrial power systems. Power Boost provides 150% output for five seconds, 200% for 50ms and up to 500% for 5ms to handle high short-duration loads. The 12V output can be adjusted from 12V to 15V, while typical efficiency reaches 92.5% at 230VAC. DC OK relay and LED indication, Remote ON/OFF, conformal coating and comprehensive protection support reliable automation and control-system operation. The slim enclosure measures 124.2 × 30 × 117.1mm.
