DRF-12V120W1GTA
120W 10A 12VDC Single Phase DIN Rail Power Supply - Spring Clamp Please ring us to discuss a great price for this product.Product Features
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
Description
The Delta DRF-12V120W1GTA is a compact 120W DIN rail power supply providing 12VDC at 10A with spring-clamp connections for quick and secure panel wiring. It accepts 90–264VAC or 127–375VDC input, while the output can be adjusted from 12V to 14V. Typical efficiency reaches 93% at 230VAC. Constant-current overload operation, short-circuit hiccup recovery and over-voltage protection support reliable industrial operation. DC OK relay and LED indication provide system monitoring, while conformal coating helps protect internal circuitry. The unit operates from -40°C to +70°C and supports full rated load up to +60°C.
