DDR-120B-48
120W 16.8 ~ 33.6VDC Input 48VDC Output DIN Rail Converter Please ring us to discuss a great price for this product.Product Features
- Compliance to BS EN/EN50155 and BS EN/EN45545-2 railway standard
- Width only 32mm
- 3 years warranty
- 150% peak load capability
- 2:1 wide input range
- 40 ~ +70°C wide working temperature
- Can be installed on DIN rail TS-35/7.5 or 15
Description
DDR-120B-48 is a 120W 48V 2.5A DIN Rail Type Converter that enables DIN Rail DC/DC integration into higher power applications. DDR-120B-48 is designed to meet both railway and ITE safety standards and is suitable for DC/DC applications such as, industrial & railway control, security control, and communication systems.DDR-120B-48 has an ultra-slim enclosure design width of only 32mm. This enables convenient installation onto TS-35/7.5 or 15 standard DIN rails without having to worry about spacing. The product design also features a 2:1 wide input range, 4000VDC IP-OP reinforced isolation, -40~70°C wide operating temperature range, 150% peak load capability, and 5G anti-vibration capability.
