DRF-48V120W1GBA
120W 2.5A 48VDC Single Phase DIN Rail Power Supply - Screw Terminal Please ring us to discuss a great price for this product.Product Features
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
- High efficiency up to 96%
Description
The Delta DRF-48V120W1GBA is a compact 48VDC industrial DIN rail power supply rated at 2.5A and 120W. Universal 90–264VAC input is complemented by 127–375VDC input capability, while the output can be adjusted from 48V to 55V. Typical efficiency is 93% at 230VAC. Screw-terminal connections support straightforward panel installation, and constant-current overload behaviour, short-circuit auto-recovery and over-voltage protection enhance reliability. DC OK relay and LED indication support status monitoring, while conformal coating helps protect the circuitry. The unit measures 123.6 × 30 × 116.8mm and operates from -40°C to +70°C.
