DRF-48V120W1GTA
120W 2.5A 48VDC Single Phase DIN Rail Power Supply - Spring Clamp Please ring us to discuss a great price for this product.Product Features
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
Description
The Delta DRF-48V120W1GTA combines a compact DIN rail format with 48VDC output at 2.5A and 120W. Spring-clamp terminals provide a fast wiring option for industrial control panels, while 90–264VAC or 127–375VDC input supports broad installation flexibility. Output is adjustable from 48V to 55V and typical efficiency reaches 93% at 230VAC. Constant-current overload operation, short-circuit hiccup recovery and over-voltage protection support reliable connected equipment. DC OK relay and LED indication, conformal coating and operation from -40°C to +70°C further strengthen its industrial suitability.
