DRF-24V120W1GBA
120W 5A 24VDC Single Phase DIN Rail Power Supply - Screw Terminal Please ring us to discuss a great price for this product.Product Features
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
Description
The Delta DRF-24V120W1GBA provides 24VDC at 5A with 120W rated output from a compact 30mm-wide DIN rail enclosure. It accepts 90–264VAC or 127–375VDC input and offers adjustable output from 24V to 28V. Typical efficiency reaches 93.5% at 230VAC. Constant-current overload operation is complemented by short-circuit hiccup recovery and over-voltage protection, while DC OK relay and LED indication provide system-status monitoring. The screw-terminal design suits conventional control-panel wiring, and conformal coating adds protection for the internal electronics. Full load is supported to +60°C within a -40°C to +70°C operating range.
