DDRH-15-24DR
15W 24VDC 0.625A Wide Input DIN Rail DC-DC Converter Please ring us to discuss a great price for this product.Product Features
- 150~1500Vdc 10:1 ultra-wide input range
- 3 years warranty
- 4KVac I/O high isolation (Reinforced isolation)
- 40~+80°C ultra-wide operating temperature (> +50°C derating)
- Fanless design, fully encapsulated, cooling by free air convection
- Can be installed on DIN rail TS-35/7.5 or 15 (DR-Type)
- Operating altitude up to 5000 meters
Description
DDRH-15 series is a 150~1500Vdc high-reliability ultra-high input DC-DC converter which can supply a stable working voltage for the load. Main features are as follows: compact size, -40~+80°C wide range operating temperature, 4kV high isolation voltage, operation at 5000m altitude, low ripple & noise, complete protections and so on. Furthermore, this series also has DIN Rail type, which is suitable for mounting on TS-35/7.5 or TS-35/15 rails. DDRH-15 is designed to meet the UL1741 and IEC62109-1 standards. It is suitable for industrial automation, surveillance, telecommunication and can be widely deployed in the applications of new energy generation, such as solar power, and windmill power generation, for instance, photovoltaic power systems, high voltage inverting, DC bus centralised application, ESS, charging pile, railway and so forth.
Style
- DIN Rail
