DRDN20-12
20A 12VDC Din Rail Type Redundancy Module Please ring us to discuss a great price for this product.Product Features
- Output current up to 20A
- Two channels input and one output
- Cooling by free air convection
- Support 1+1 and N+1 redundancy system
- Built-in two channels DC OK signal and alarm relay contact
- Ultra wide operating temperature
Description
The DRDN20 series is a 20A redundancy module that can be used with a power supply to improve overall system operation reliability. Product key features include: 12V / 24V / 48V input voltage for selection, support for N+1 and 1+1 redundancy systems, built-in two-rail DC input contacts and single output. The MOSFET technology implemented can reduce heat loss and reduce the voltage difference between the input and output voltages. Additional features include built-in 2-channel DC OK relay contacts for monitoring output status, ultra-wide operating temperature of -40 to +80°C, and a narrow width (32mm).
