DRF-24V240W1GBA
240W 10A 24VDC Single Phase DIN Rail Power Supply - Screw Terminal Please ring us to discuss a great price for this product.Product Features
- Available with screw-terminal or spring-clamp connections
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
Description
The Delta DRF-24V240W1GBA is a 240W industrial DIN rail power supply delivering regulated 24VDC at 10A. Its 90–264VAC and 127–375VDC input ranges provide flexibility for industrial control and automation equipment, while the output can be adjusted from 24V to 28V. Typical efficiency reaches 94.5% at 230VAC. Constant-current overload operation, short-circuit hiccup recovery and over-voltage protection support dependable operation under fault and load conditions. The unit also includes DC OK relay and LED indication, conformal coating and screw-terminal connections. Full rated output is supported up to +60°C.
