DRF-12V240W1PBA
240W 20A 12VDC High Reliability DIN Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- 85–277VAC or 100–400VDC wide input range
- Withstands 305VAC input for 60 seconds
- Power Boost: 150% for 5 seconds, 200% for 50ms and 500% for 5ms
- Full-load operation up to +60°C
- Wide -40°C to +80°C operating temperature range with derating
- DC OK relay contact and LED status indication
- Remote ON/OFF control
- Conformal coating for additional PCB protection
- Short-circuit, overload and over-voltage protection
- SEMI F47 compliance, Class B EMC performance and 5-year warranty
Description
The Delta DRF-12V240W1PBA is a high-current industrial DIN rail power supply delivering 12VDC at 20A with 240W rated output. It accepts 85–277VAC or 100–400VDC input and withstands 305VAC for 60 seconds, providing flexibility for demanding automation and industrial power systems. High Power Boost capability supports temporary load requirements with 150% output for five seconds, 200% for 50ms and up to 500% for 5ms. The 12V output is adjustable from 12V to 15V, while typical efficiency reaches 93% at 230VAC. DC OK relay and LED indication, Remote ON/OFF, conformal coating and comprehensive protection support reliable system integration. The unit measures 124.2 × 40 × 117.1mm.
