DRF-12V240W1GBA
240W 20A 12VDC Single Phase DIN Rail Power Supply - Screw Terminal Please ring us to discuss a great price for this product.Product Features
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
Description
The Delta DRF-12V240W1GBA delivers a high-current 12VDC output at 20A with 240W rated power. It supports 90–264VAC or 127–375VDC input and provides an adjustable 12–14VDC output. Typical efficiency reaches 93.5% at 230VAC. Constant-current overload capability supports demanding industrial loads, backed by short-circuit hiccup recovery and over-voltage protection. DC OK relay and LED indication provide operating status information, while conformal coating supports use in demanding equipment environments. Screw terminals simplify conventional panel wiring, and the 40mm-wide enclosure helps conserve DIN rail space.
