DRF-12V240W1GTA
240W 20A 12VDC Single Phase DIN Rail Power Supply - Spring Clamp Please ring us to discuss a great price for this product.Product Features
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
Description
The Delta DRF-12V240W1GTA provides high-current 12VDC power at 20A and 240W in a compact DIN rail format with spring-clamp terminals. It accepts 90–264VAC or 127–375VDC input and provides adjustable 12–14VDC output. Typical efficiency reaches 93.5% at 230VAC. The constant-current overload characteristic supports demanding industrial loads, while short-circuit hiccup recovery and over-voltage protection provide fault protection. DC OK relay and LED indication support control-system monitoring, and conformal coating provides additional PCB protection. Full rated output is supported up to +60°C.
