DDRH-240-48
240W 250 ~ 1500VDC Input 48VDC Output DIN Rail Converter Please ring us to discuss a great price for this product.Product Features
- 4KVac I/O high isolation (Reinforced isolation)
- Operating altitude up to 5000 meters
- 40~+80°C ultra-wide operating temperature (> +50°C derating)
- 85.5mm slim width
- Over voltage category II
- 3 years warranty
- Current sharing up to 960W (3+1)
- Withstand 1700Vdc surge input for 10 seconds
- 250~1500Vdc 6:1 ultra-wide input range
Description
DDRH-240 series is a 250~1500VDC high reliable ultra-high input DIN rail type DC-DC converter which can supply a stable working voltage for the load. It is suitable to be mounted on TS-35/7.5 or 15 rails. Main features are as follows: easy to install DIN rail type, narrow width (85.5mm) in slim design, -40ºC ~ +80°C temperature tolerance, 4KVac reinforced isolation, and supports current sharing up to 960W (3+1). High efficiency, low ripple and noise, and comprehensive protection functions make it ideal for demanding environments.DDRH-240 complies with UL1741 and BS EN/EN61000-6-2 immunity standards for industrial use. It suits a wide range of applications, including photovoltaic and wind power systems, high-voltage DC bus infrastructure, ESS (Energy Storage Systems), charging infrastructure, and railway systems.
