DDR-240C-48
240W 33.6 ~ 67.2VDC Input 48VDC Output DIN Rail Converter Please ring us to discuss a great price for this product.Product Features
- 3 years warranty
- Compliance to BS EN/EN50155 and BS EN/EN45545-2 railway standard
- Current sharing up to 960W (3+1)
- DC output adjustable
- 4KVdc I/O isolation (Reinforced isolation)
- 40 ~ +70°C wide working temperature
- 150% peak load capability
- 2:1 wide input range
- Width only 40mm
- Can be installed on DIN rail TS-35/7.5 or 15
Description
DDR-240C-48 Series is a 240W DIN Rail Type DC-DC converter with main features including DIN rail type, easy installation, ultra slim width, 2:1 wide input voltage, fanless design, -40~+70°C wide operating temperature, 4KVDC, I/O isolation, 150% peak load, current sharing, DC OK, adjustable output voltage and full protective functions. This model has an input of 33.6~67.2V and a 48V output, and can be used for industrial & railway control, security control, communication systems and other fields. Suitable applications include to DC buck/boost regulator, increasing system insulation level and voltage drop compensation along the cable, etc. For more information and to discuss your requirements, please contact us.
