TDR-240-48
240W 48VDC 5A Three Phase PFC Industrial DIN Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- DC OK relay contact
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Cooling by free air convection
- 3 years warranty
- Three-Phase 340 – 550VAC wide range input (Dual phase operation possible)
- Built-in passive PFC function compliance to BS EN/EN61000-3-2
- High efficiency 92% and low power dissipation
- 63mm slim width
- Full power between -30~+60°C
Description
TDR-240 is an economical, slim 240W Din rail power supply series, adapted to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed to be 63mm in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input from 3Ø 340VAC to 550VAC (Dual Phase operation possible) and conforms to BS EN/EN61000-3-2, the norm the European Union regulates for harmonic current. TDR-240 is designed with a metal housing that enhances the unit's power dissipation. With working efficiency up to 92%, the entire series can operate at the ambient temperature between -30°C and 70°C under air convection. It is equipped with a constant current mode for overload protection, fitting various inductive or capacitive applications. The complete protection functions and relevant certificates for industrial control apparatus (UL61010-1, UL61010-2-201, BS EN/EN61558-1, BS EN/EN61558-2-16, EAC TP TC 004 approved, etc.) make TDR-240 a very competitive power supply solution for industrial applications.
