DRF-48V240W1PBA
240W 5A 48VDC High Reliability DIN Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- 85–277VAC or 100–400VDC wide input range
- Withstands 305VAC input for 60 seconds
- Power Boost: 150% for 5 seconds, 200% for 50ms and 500% for 5ms
- Full-load operation up to +60°C
- Wide -40°C to +80°C operating temperature range with derating
- DC OK relay contact and LED status indication
- Remote ON/OFF control
- Conformal coating for additional PCB protection
- Short-circuit, overload and over-voltage protection
- SEMI F47 compliance, Class B EMC performance and 5-year warranty
Description
The Delta DRF-48V240W1PBA is a high-reliability 48VDC DIN rail power supply delivering up to 5A and 240W for industrial control, telecommunications and OEM systems. It operates from 85–277VAC or 100–400VDC input and withstands 305VAC for 60 seconds. Power Boost supports equipment with temporary high-load requirements by providing 150% output for five seconds, 200% for 50ms and up to 500% for 5ms. The 48V output can be adjusted from 48V to 56V and achieves 93.5% typical efficiency at 230VAC. Remote ON/OFF, DC OK relay and LED status indication, conformal coating and comprehensive protection support dependable equipment integration.
