DRF-48V240W1GTA
240W 5A 48VDC Single Phase DIN Rail Power Supply - Spring Clamp Please ring us to discuss a great price for this product.Product Features
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
Description
The Delta DRF-48V240W1GTA provides 48VDC at 5A with 240W rated power for industrial automation, communications and control applications. Spring-clamp terminals provide a fast panel-wiring solution, while input capability covers 90–264VAC and 127–375VDC. Output is adjustable from 48V to 55V and typical efficiency reaches 94% at 230VAC. Constant-current overload operation is supported by short-circuit hiccup recovery and over-voltage protection. DC OK relay and LED indication enable operating-status monitoring, while conformal coating supports reliable operation in demanding equipment environments.
