DDR-30G-5
30W 9 ~ 36VDC Input 5VDC Output DIN Rail Converter Please ring us to discuss a great price for this product.Product Features
- Cooling by free air convection
- DC output adjustable (+10%)
- No minimum load required
- 40 ~ +85°C wide working temperature
- 3 years warranty
- 4KVdc I/O isolation (Reinforced isolation)
- Can be installed on DIN rail TS-35/7.5 or 15
- 4:1 ultra wide input range
- Width only 17.5mm (1SU)
Description
DDR-30G-5 is a 30W 5V 6A DIN rail type converter with main features including DIN rail-type easy installation, ultra slim width (35mm), 4:1 ultra wide input voltage, -40~+85°C operating temperature, 4kVdc I/O isolation, adjustable output voltage (± 10%) and full protective functions. DDR-30G-5 has an input of 9~36V and an output of 5V and can be used for industrial control, security control, communication systems and other fields. Suitable applications are a DC buck/boost regulator, increasing the system insulation level and voltage drop compensation along cables.
