HDR-30-48
36W 48VDC 0.75A Ultra Slim Step Shape DIN Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- Isolation class II
- DIN rail TS-35/7.5 or 15 mountable
- Pass LPS (Limited power source)
- Universal input 85-264VAC(277VAC operational)
- Cooling by free air convection (Working temperature: -30~+70°C)
- Ultra slim design with 35mm(2SU) width
- 3 years warranty
- DC output voltage adjustable
- No load power consumption<0.3W
- Protections: Short circuit / Overload / Over voltage
- LED indicator for power on
Description
HDR-30 is an economical, ultra slim 30W DIN rail power supply series, adapted to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed 35mm(2SU) in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input from 85VAC to 264VAC(277VAC operational) and conforms to BS EN/EN61000-3-2, the norm the European Union regulates for harmonic current. HDR-30 is designed with tight housing that can effectively protect users from electric hazards. With working efficiency up to 90%, the entire series can operate at the ambient temperature between -30°C and 70°C under air convection. The complete protection functions and relevant certificates for home automation and industrial control apparatus (IEC62368-1, UL508, UL62368-1, BS EN/EN61558-2-16) make HDR-30 a very competitive power supply solution for household and industrial applications.
