MDR-40-48
39.8W 48VDC 0.83A Slim Industrial Din Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- LED indicator for power on
- 3 years warranty
- DC OK relay contact
- Can be installed on DIN rail TS-35/7.5 or 15
- 100% full load burn-in test
- Cooling by free air convection
- Class I, Div 2 Hazardous Locations T4
- No load power consumption<0.75W
- Protections: Short circuit / Overload / Over voltage
- Universal AC input/Full range
Description
MDR-40 Series is a slim-line DIN rail Class I switching power supply. Designed with a fully isolated plastic case to prevent user contact and the risk of shock. Featuring up to 85% efficiency, this series can be cooled using only free air convection up to 70°C, which significantly increases the reliability and lifetime of the power supply. Other standard features include its low no-load power consumption, to save energy, short circuit, overload and over voltage protections and the DC OK relay contact for monitoring the status of the PSU.
