DRF-48V480W1PBA
480W 10A 48VDC High Reliability DIN Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- 85–277VAC or 100–400VDC wide input range
- Withstands 305VAC input for 60 seconds
- Power Boost: 150% for 5 seconds, 200% for 50ms and 500% for 5ms
- Full-load operation up to +60°C
- Wide -40°C to +80°C operating temperature range with derating
- DC OK relay contact and LED status indication
- Remote ON/OFF control
- Conformal coating for additional PCB protection
- Short-circuit, overload and over-voltage protection
- SEMI F47 compliance, Class B EMC performance and 5-year warranty
Description
The Delta DRF-48V480W1PBA provides 48VDC at 10A with 480W rated output for industrial automation, telecommunications, networking and other demanding DC power systems. It accepts 85–277VAC or 100–400VDC input and withstands 305VAC for 60 seconds. High Power Boost capability provides 150% output for five seconds, 200% for 50ms and up to 500% for 5ms, helping support equipment with demanding start-up and transient loads. Typical efficiency reaches 95.5% at 230VAC, while the output voltage can be adjusted from 48V to 56V. Remote ON/OFF, DC OK relay and LED indication, conformal coating and comprehensive protection support reliable industrial system integration.
