DRF-48V480W1GBA
480W 10A 48VDC Single Phase DIN Rail Power Supply - Screw Terminal Please ring us to discuss a great price for this product.Product Features
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
Description
The Delta DRF-48V480W1GBA is a high-power 48VDC DIN rail power supply delivering 10A and 480W for industrial machinery, control systems and communications equipment. It operates from 90–264VAC or 127–375VDC and offers an adjustable 48–55VDC output. Typical efficiency is 95% at 230VAC. Constant-current overload operation helps support demanding loads, while short-circuit hiccup recovery and over-voltage protection provide fault protection. The unit combines screw-terminal connections with DC OK relay and LED indication, conformal coating and full-load capability up to +60°C.
