DRF-48V480W1GTA
480W 10A 48VDC Single Phase DIN Rail Power Supply - Spring Clamp Please ring us to discuss a great price for this product.Product Features
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
- High efficiency up to 96%
Description
The Delta DRF-48V480W1GTA provides 48VDC at 10A with 480W rated output in a compact industrial DIN rail format. Its spring-clamp terminals support efficient panel wiring, while 90–264VAC and 127–375VDC input capability provide broad supply compatibility. The output can be adjusted from 48V to 55V, with 95% typical efficiency at 230VAC. Constant-current overload operation, short-circuit hiccup recovery and over-voltage protection support dependable performance. DC OK relay and LED indication, conformal coating and operation from -40°C to +70°C further support demanding industrial applications.
