DRF-48V480W3GTA
480W 10A 48VDC Three/Two Phase DIN Rail Power Supply - Spring Clamp Please ring us to discuss a great price for this product.Product Features
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
Description
The Delta DRF-48V480W3GTA provides 48VDC at 10A with 480W rated output from a high-efficiency industrial DIN rail platform. Spring-clamp terminals support efficient control-panel wiring, while input capability includes 3 × 320–575VAC, 2 × 340–575VAC and 450–800VDC. Output is adjustable from 48V to 56V and typical efficiency reaches 95.5% at three-phase 400/500VAC. Constant-current overload operation, short-circuit hiccup recovery and over-voltage auto-recovery support dependable system protection. The IP20 unit also includes DC OK relay and LED indication, conformal coating and cold-start operation at -40°C.
