DDR-480B-48
480W 16.8 ~ 33.6VDC Input 48VDC Output DIN Rail Converter Please ring us to discuss a great price for this product.Product Features
- 2:1 wide input range
- Operating altitude up to 5000 meters
- 40~+80°C wide operating temperature
- Width only 85.5mm
- Compliance to BS EN/EN50155 and BS EN/EN45545-2 railway standard
- 150% peak load capability
- 4KVdc I/O isolation (Reinforced isolation)
- Current sharing up to 1920W (3+1)
- 3 years warranty
- Can be installed on DIN rail TS-35/7.5 or 15
Description
DDR-480 series is a 480W DIN Rail type DC-DC converter with main features including DIN rail-type easy installation, ultra slim width (85.5mm), 2:1 wide input voltage, fanless design, -40~+80°C wide operating temperature, 4KVdc I/O isolation, 150% peak load, current sharing, DC OK, adjustable output voltage and full protective functions. This series of models has various input options: 16.8~33.6V / 33.6~67.2V / 67.2~154V and multiple output options: 12V / 24V / 48V and can be used for industrial & railway control, security control, communication system and other fields. Suitable applications include DC buck/boost regulator, increasing system insulation level and voltage drop compensation along the cable.
