DRF-24V480W3GBA
480W 20A 24VDC Three/Two Phase DIN Rail Power Supply - Screw Terminal Please ring us to discuss a great price for this product.Product Features
- Available with screw-terminal or spring-clamp connections
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
Description
The Delta DRF-24V480W3GBA delivers 24VDC at 20A with 480W rated output for demanding industrial machinery, automation and process-control installations. Input compatibility includes 3 × 320–575VAC, 2 × 340–575VAC and 450–800VDC. The adjustable 24–28VDC output reaches 94% typical efficiency at three-phase 400/500VAC. The IP20 screw-terminal design provides 110–150% constant-current overload protection, short-circuit hiccup recovery and over-voltage auto-recovery. DC OK relay and LED indication support system monitoring, while conformal coating, -40°C cold-start capability and full-load operation to +55°C support demanding industrial environments.
