XTR-480-48
480W 3-Phase Input 48VDC 10A Industrial DIN Rail Power Supply with Terminal Blocks Please ring us to discuss a great price for this product.Product Features
- 200% peak power capability
- Ultra low inrush current <10A
- 63mm ultra slim width
- Operating altitude up to 5000 meters
- 5 years warranty
- High efficiency up to 95.5% and no load power dissipation <3.1W by R.C.
- Three-Phase 320 ~ 600Vac wide range input
- 40ºC ~ +85℃ wide range operation temperature (>+60℃ derating)
- Built-in constant current limiting circuit
- Current sharing up to 1920W (3+1) for parallel use
Description
The XTR-480 series is a 480W AC/DC 3Ø 320~600Vac input ultra-slim industrial high-reliability DIN rail power. Key features of this series include a narrow 63 mm casing, optimising system installation space. It boasts a maximum efficiency of 95.5% and a low standby power consumption of
Style
- Terminal Blocks
