DDRH-60-12
60W 150 ~ 1500VDC Input 12VDC Output DIN Rail Converter Please ring us to discuss a great price for this product.Product Features
- 3 years warranty
- DC output voltage adjustable (+20%)
- 57mm slim width
- Can be installed on DIN rail TS-35/7.5 or 15
- 4KVac I/O high isolation (Reinforced isolation)
- 150~1500Vdc 10:1 ultra-wide input range
- 30~+80°C ultra-wide operating temperature (> +55°C derating)
Description
The DDRH-60-12 is the first ultra-wide input 60W DIN rail DC/DC Converter from MEAN WELL. The product is ideally suited to solar and wind powered renewable energy applications, as well as DC power distribution systems that require high voltage to low voltage conversion. DDRH-60-12 is a 150 ~ 1500 VDC ultra-high input DIN rail type DC-DC Converter which can supply stable working voltage for the load. The DDRH-60-12 is suitable to be mounted on TS-35/7.5 or TS-35/15 rails. The device is easy to install on a DIN rail with a narrow width of 57mm and a slim design. In addition, the device has a wide operating temperature of -30~+80°C and a high isolation voltage of 4KVAC. The DDRH-60-12 is also able to operate at 5000m altitude. DDRH-60-12 is compliant with EN-61000-6-2 standard regarding immunity for industrial environments. It is suitable for industrial automation, surveillance, telecommunication and solar power and windmill power generation. For more information and to discuss your requirements, please contact a member of our team.
