DDR-60L-5
60W 18 ~ 75VDC Input 5VDC Output DIN Rail Converter Please ring us to discuss a great price for this product.Product Features
- 4KVdc I/O isolation (Reinforced isolation)
- Cooling by free air convection
- No minimum load required
- Can be installed on DIN rail TS-35/7.5 or 15
- DC output adjustable (+10%)
- 40~+85°C wide working temperature
- 3 years warranty
- Width only 52.5mm (3SU)
- 4:1 ultra wide input range
Description
DDR-60L-5 is a 60W 5V 12A DIN rail DC-DC converter with main features including DIN rail-type easy installation, ultra slim width (52.5mm), 4:1 ultra wide input voltage, -40~+85°C operating temperature, 4KVdc I/O isolation, adjustable output voltage (± 10%) and full protective functions. DDR-60L-5 has an input of 18~75V and an output of 5V and can be used for industrial control, security control, communication system and other fields. Suitable applications are DC buck/boost regulator, increasing system insulation level and voltage drop compensation along cables.
