HDR-100-12N
90W 12VDC 7.5A NON-LPS DIN Rail Power Supply Please ring us to discuss a great price for this product.Product Features
- DIN rail TS-35/7.5 or 15 mountable
- DC output voltage adjustable
- LED power on indicator
- Cooling by free air convection
- No load power consumption <0.3W
- Ultra slim design
- 3 years warranty
- Protections: Short circuit / Overload / Over voltage
Description
HDR-100 is an economical, ultra slim 100W DIN rail power supply series, adapted to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed 70mm(4SU) in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input from 85VAC to 264VAC (277VAC operational) and conforms to BS EN/EN61000-3-2, the norm the European Union regulates for harmonic current. HDR-100 is designed with plastic housing that can effectively protect users from electric hazards. With working efficiency up to 90%, the entire series can operate at the ambient temperature between -30°C and 70°C under air convection. The complete protection functions and relevant certificates for home automation and industrial control apparatus (IEC62368-1, UL508, UL62368-1, BS EN/EN61558-2-16) make HDR-100 a very competitive power supply solution for household and industrial applications.
Style
- NON-LPS
