XTR-960-36LA
957.6W 3-Phase Input 36VDC 26.66A Industrial DIN Rail Power Supply with Lever Actuated Terminals Please ring us to discuss a great price for this product.Product Features
- Operating altitude up to 5000 meters
- 40ºC ~ +85ºC wide range operation temperature (>+60ºC derating)
- 200% peak power capability
- 96mm ultra slim width
- High efficiency up to 96% and no load power dissipation <3.1W by R.C.
- Current sharing up to 3840W (3+1) for parallel use
- 5 years warranty
- Three-Phase 320 ~ 600Vac wide range input
Description
The XTR-960 series is a 960W AC/DC 3Ø 320~600Vac input ultra-slim industrial high-reliability DIN rail power. Key features of this series include a narrow 96 mm casing, optimising system installation space. It boasts a maximum efficiency of 96% and a low standby power consumption of
Style
- Lever Actuated Terminals
