DRF-48V960W3GBA
960W 20A 48VDC Three/Two Phase DIN Rail Power Supply - Screw Terminal Please ring us to discuss a great price for this product.Product Features
- Full rated output at elevated ambient temperatures
- DC OK relay contact and LED status indication
- Conformal-coated electronics for improved environmental protection
- Short-circuit, overload and over-voltage protection
- AC and DC input capability across the Force-GT range
- Available with screw-terminal or spring-clamp connections
- High efficiency up to 96%
- Surge capacity up to 6kV with SPD
- Constant-current mode for charging and demanding DC loads
- Wide operating temperature range down to -40°C
Description
The Delta DRF-48V960W3GBA is the highest-efficiency Force-GT model in the supplied operations data, delivering 48VDC at 20A with 960W rated output. It accepts 3 × 320–575VAC, 2 × 340–575VAC or 450–800VDC input and provides an adjustable 48–56VDC output. Typical efficiency reaches 96% at three-phase 400/500VAC. The IP20 screw-terminal design incorporates 110–150% constant-current overload protection, short-circuit hiccup recovery and over-voltage auto-recovery. DC OK relay and LED indication, conformal coating, -40°C cold-start capability and full-load operation up to +55°C support high-power industrial automation and machine-control applications.
