XDR-960E-36
960W 36VDC Economical Ultra Slim Industrial DIN Rail Power Supplies Please ring us to discuss a great price for this product.Product Features
- 3 years warranty
- Fanless design, cooling by free air convection
- Current sharing up to 3840W (3+1) for parallel use
- Operating altitude up to 5000 meters
- 40~+70°C wide range operation temperature (>+50°C derating)
- Protections: Short circuit / Overload / Over voltage / Over temperature
- 180~264Vac input with PFC
- High efficiency up to 95.5% and no load power dissipation <3.6W
- L132 x W96 x H125.2mm
Description
The MEAN WELL XDR-960E-36 is a 960W class AC/DC economical ultra slim industrial DIN rail power supply designed for compact control panels and industrial equipment requiring a regulated 36VDC output. It delivers 26.6A rated current and 957.6W rated power, with an adjustable output range of 36V to 42V. The unit accepts 180-264VAC input and 254.5-370VDC input, provides 95% typical efficiency and uses fanless free air convection cooling to support reliable operation in enclosed systems. With a 96 x 125.2 x 132mm DIN rail housing, built-in PFC, built-in constant current limiting, DC OK relay contact, droop mode current sharing for parallel operation up to 3840W using 3+1 units, overvoltage category III, operation from -40°C to +70°C with derating and protection against short circuit, overload, overvoltage and overtemperature, the XDR-960E-36 is suitable for industrial control systems, factory automation, semiconductor fabrication equipment, electro-mechanical apparatus and battery charger applications.
