NSP-2400-60
2400W 40A 60VDC High Reliability Enclosed Power Supply Please ring us to discuss a great price for this product.Product Features
- 85~305Vac input with PFC (277Vac available)
- Global certificates in multi-fields
- 200% peak power capability
- High efficiency up to 93%
- Output voltage 0~120% and output current 0~100% programmable
- Current sharing up to 9600W (3+1) for parallel use
- CANBus built-in
- -40~85℃ wide range operation temperature (> +60℃ derating)
- Extremely low leakage current <500uA, 2 x MOPP, suitable for BF medical applications
- Protections: Short circuit / Overload / Over voltage / Over temperature
Description
The MEAN WELL NSP-2400-60 is the highest-voltage standard model in the NSP-2400 range, delivering 60VDC at up to 40A with 2400W continuous output. Its ultra-wide 85–305VAC input with PFC supports industrial, communications, automation, medical and electronic equipment across a broad range of mains systems. At 220VAC input and above, the unit provides up to 4800W and 80A peak output for up to five seconds. Output voltage is adjustable from 54V to 72V, while typical efficiency reaches 93%. Programmable voltage and current, CANBus, Remote ON/OFF, Remote Sense, DC OK signalling and auxiliary outputs provide extensive system-control capability. Active current sharing supports parallel systems up to 9600W.
