NSP-500-24
24V 21A 504W Enclosed AC-DC Power Supply Please ring us to discuss a great price for this product.Product Features
- 24V DC output for automation, controls, security, telecom and industrial equipment
- Rated output current of 21A
- Rated output power of 504W
- 1000W peak power capability for short-duration load demands
- Peak current capability of 41.7A for 5 seconds
- Wide 85 to 305Vac input range with 120 to 431Vdc input support
- Active PFC for improved input power performance
- Typical efficiency of 94%
- Output voltage adjustment range from 21V to 26V
- Maximum ripple and noise of 240mVp-p
- Low leakage current below 350µA
- Remote ON/OFF control for system-level power management
- Remote sense function to help compensate voltage drop across load wiring
- DC OK signal for output status monitoring
- Built-in fan ON/OFF control with noise below 45dB
- Built-in protection against short circuit, overload, over voltage and over temperature
- 5-year warranty
Description
The MEAN WELL NSP-500-24 is a high-reliability 24VDC enclosed power supply delivering up to 21A and 504W continuous output. Its ultra-wide 85–305VAC input with PFC makes it suitable for industrial automation, control systems, security equipment, charging applications and other systems requiring dependable 24V power. The unit provides up to 1000W and 41.7A peak output for five seconds to support demanding transient loads. Output voltage can be adjusted from 21V to 26V, with typical efficiency reaching 94%. Temperature-controlled forced-air cooling, Remote ON/OFF, Remote Sense and DC OK signalling provide reliable operation and flexible system integration.
