MPM-10-3.3
8.3W 3.3V 2.5A Medical Encapsulated Type Power Supply Please ring us to discuss a great price for this product.Product Features
- EMI Class B for Class II configuration
- Extremely low leakage current
- Wide operating temperature range: -30°C to +85°C
- No minimum load required
- 3 years warranty
- 1.8" × 1" compact size
- Medical safety approved (2 × MOPP) according to ANSI/AAMI ES60601-1 and IEC/BS EN/EN60601-1
- No load power consumption < 0.075W
- Suitable for BF application with appropriate system consideration
Description
MPM-10-3.3 is an 8.3W 3.3V 2.5A high-density and small-sized AC/DC module type medical grade power supply offered in pin type. It features the operation for 80~264VAC, a no-load power consumption of less than 0.075W, a high efficiency Class II (no FG) double insulation, outstanding dissipation, and high lifespan, thanks to the interior potting, 5G anti-vibration, high EMC performance, and 4KVAC isolation. The design observes IEC/EN60601-1 and ANSI/AAMI ES60601-1 version three 2XMOPP level and has an ultra-low leakage current (
