MPM-90-15
85.05W 5.67A 15VDC High Reliability PCB-Mount Medical Power Module Please ring us to discuss a great price for this product.Product Features
- 100W peak power capability for 10 seconds
- Protections: Short circuit / Overload / Over voltage
- Isolation Class II
- EMI Class B without additional components
- Extremely low leakage current
- Wide operating temperature range -30~+80℃
- No load power consumption <0.1W
- Suitable for BF application with appropriate system consideration
- Medical safety approved with 2 x MOPP
- PCB, chassis or screw terminal mounting version
Description
The MEAN WELL MPM-90-15 is a compact PCB-mount medical power module delivering 15VDC at 5.67A with 85.05W continuous convection-cooled output. It can provide up to 6.23A and 93.5W peak power for 10 seconds, supporting equipment with temporary higher-load requirements. The module operates from 80–264VAC or 113–370VDC input and achieves 92.5% typical efficiency. Medical safety performance includes 2 x MOPP isolation, ultra-low touch current and suitability for BF applications with appropriate system consideration. Class II insulation and EMI Class B performance support straightforward integration, while short-circuit, overload, over-voltage and over-temperature protection provide comprehensive electrical protection. The PCB-mount enclosure measures 87 × 52 × 29.5mm.
