MPM-90-48ST
90.2W 1.88A 48VDC High Reliability Screw Terminal Medical Power Module Please ring us to discuss a great price for this product.Product Features
- PCB, chassis or screw terminal mounting version
- Medical safety approved with 2 x MOPP
- Suitable for BF application with appropriate system consideration
- No load power consumption <0.1W
- Extremely low leakage current
- Wide operating temperature range -30~+80℃
- EMI Class B without additional components
- Isolation Class II
- Protections: Short circuit / Overload / Over voltage
- 100W peak power capability for 10 seconds
Description
The MEAN WELL MPM-90-48ST is a screw-terminal medical power module providing 48VDC at 1.88A with 90.2W continuous convection-cooled output. For short-duration higher-load requirements, the unit provides up to 2.07A and 99.2W peak power for 10 seconds. Its 80–264VAC or 113–370VDC input provides broad mains compatibility, while typical efficiency reaches 93%. Medical-grade 2 x MOPP isolation, ultra-low touch current and suitability for BF applications support integration into appropriate medical equipment. The Class II design provides EMI Class B performance without additional components and includes comprehensive short-circuit, overload, over-voltage and over-temperature protection. The screw-terminal chassis measures 109 × 52 × 33.5mm and withstands 5G vibration.
