MPM-90-24
90W 3.75A 24VDC High Reliability PCB-Mount Medical Power Module Please ring us to discuss a great price for this product.Product Features
- PCB, chassis or screw terminal mounting version
- Medical safety approved with 2 x MOPP
- Suitable for BF application with appropriate system consideration
- No load power consumption <0.1W
- Extremely low leakage current
- Wide operating temperature range -30~+80℃
- Isolation Class II
- EMI Class B without additional components
- Protections: Short circuit / Overload / Over voltage
- 100W peak power capability for 10 seconds
Description
The MEAN WELL MPM-90-24 is a compact 24VDC medical power module designed for direct PCB mounting. It delivers 3.75A and 90W continuously through convection cooling, with peak capability of 4.13A and 99W for up to 10 seconds. An 80–264VAC or 113–370VDC input provides broad mains compatibility, while typical efficiency reaches 93%. Medical safety features include 2 x MOPP isolation, ultra-low touch current and suitability for BF applications when incorporated into an appropriate system. Class II insulation and EMI Class B performance help simplify equipment integration. Short-circuit, overload, over-voltage and over-temperature protection support dependable operation, while the compact 87 × 52 × 29.5mm format helps maximise available PCB space.
