MPM-90-24ST
90W 3.75A 24VDC High Reliability Screw Terminal Medical Power Module Please ring us to discuss a great price for this product.Product Features
- Wide operating temperature range -30~+80℃
- EMI Class B without additional components
- Isolation Class II
- Protections: Short circuit / Overload / Over voltage
- 100W peak power capability for 10 seconds
- PCB, chassis or screw terminal mounting version
- Medical safety approved with 2 x MOPP
- Suitable for BF application with appropriate system consideration
- No load power consumption <0.1W
- Extremely low leakage current
Description
The MEAN WELL MPM-90-24ST provides high-density 24VDC medical power in a screw-terminal chassis for convenient system installation. It delivers 3.75A and 90W continuous convection-cooled output, increasing to 4.13A and 99W for up to 10 seconds when additional short-duration power is required. The module accepts 80–264VAC or 113–370VDC input and achieves 93% typical efficiency. Its medical-grade design provides 2 x MOPP isolation, ultra-low touch current and suitability for BF applications with appropriate system consideration. Class II insulation, EMI Class B performance and comprehensive electrical protection support reliable integration. The ST configuration measures 109 × 52 × 33.5mm and withstands 5G vibration.
