KAA-8R-10
8 Channel 10A Per Channel KNX Actuator with Remote On-Off Please ring us to discuss a great price for this product.Product Features
- 8 channel actuator in a compact size
- Programmable various time and scene functions
- Suitable for various and mixed applications
- Program via ETS5.0 software
- Support KNX Data Secure
- For AX, C-load, capacitive & inductive loads
- 3 years warranty
- Manual control via push button
Description
The KNX actuator is an 8-channel device featuring high-quality independent latching relays suitable for controlling switches, shutters, or various mixed load applications. Its compact 4-unit (72 mm wide) modular design allows for simple installation on 35 mm DIN mounting rails, making it ideal for EIB/KNX system integration.Communication with the KNX bus is done via a dedicated bus connection terminal. This actuator also supports KNX Data Secure, providing enhanced protection against tampering in smart building environments. Configuration is managed through the ETS project software.The actuator is well-suited for switching various load types, including ohmic, capacitive, and inductive loads. It's commonly used with LED drivers and motor controls, such as in shutter or blind systems. Powered directly through the EIB/KNX line, the unit does not require any external power supply, offering reliable operation and easy deployment in automation systems. For more information and to discuss your requirements, please get in touch with our team.
